Dragon's Lair
Platform: Arcade
Game: Dragon's Lair   Display Type: raster
Manufacturer: Cinematronics   Resolution (W x H): 704 x 480
Year Released: 1983   Orientation: H
Main CPU: Z80   Audio Channels: 2
# of Players: 1   # of Buttons: 1
# Simul. Players: 2P alt   Genres: Platform, Run Jump

Controls: 8 way Joystick

MAME Driver Status: preliminary   MAME Driver Emulation: preliminary
MAME Driver Sound: good   MAME Driver Color: good
MAME Driver Graphics: good
MAME Source File: \src\mame\drivers\dlair.cpp

Dip switches used by this game

The link below will take you to another page that shows all the dip switch settings for this game.  Dip Switches have their own page to make it more printer friendly.
Dragon's Lair Dip Switch Settings


Memory Map for this game

If you need a memory map for your game that you are working on repairing, you can view that with the link below.
Dragon's Lair Memory Map

ROMS used by this game

The following is a list of ROMS that are used by this game.  Many games had multiple versions of ROMS.  If you are not sure which version of ROM you have, you can use the ROM Identification Page to upload an image and find out.
Rom Name Ascending
Rom Size
SHA1
CRC32
Fluke 9010A Signature
Location
Expand Dragon's Lair (US Beta 1, Pioneer PR-7820) found in MAME ROM Set: dlair_1 Released in 1983 in the zip file
Expand Dragon's Lair (US Beta 2?, Pioneer PR-7820) found in MAME ROM Set: dlair_2 Released in 1983 in the zip file
Expand Dragon's Lair (US Rev. A, Pioneer PR-7820) found in MAME ROM Set: dlaira Released in 1983 in the zip file dlairb.zip
Expand Dragon's Lair (US Rev. B, Pioneer PR-7820) found in MAME ROM Set: dlairb Released in 1983 in the zip file dlairb.zip
Expand Dragon's Lair (US Rev. C, Pioneer PR-7820) found in MAME ROM Set: dlairc Released in 1983 in the zip file dlairc.zip
Expand Dragon's Lair (US Rev. D, Pioneer LD-V1000) found in MAME ROM Set: dlaird Released in 1983 in the zip file dlaird.zip
Expand Dragon's Lair (US Rev. E) found in MAME ROM Set: dlaire Released in 1983 in the zip file dlaire.zip
Expand Dragon's Lair (US Rev. F) found in MAME ROM Set: dlairf Released in 1983 in the zip file dlairf.zip
Expand Dragon's Lair (US Rev. F2) found in MAME ROM Set: dlair Released in 1983 in the zip file dlair.zip
